Hydraulic ORFS Fittings

When leakage is not an option, ordinary fittings stop working

These are hydraulic fittings that use an O ring to prevent leakage. When there is excessive pressure, vibration, or oil flow in a hydraulic system, the possibility of oil leakage from normal fittings increases. In this situation ORFS fittings provides leak free and safe connection

Unlike conventional hydraulic connectors, ORFS hydraulic fittings are designed specifically for applications where even minor oil leakage is unacceptable.

How does Hydraulic ORFS Fitting works

Hydraulic ORFS fittings have a rubber or elastomer O-ring mounted on the flat face of the fitting, which creates the primary sealing surface.

Process of working:

1. The ORFS fitting is connected to the flat faced port.
2. When tightened, the O ring compresses and forms a seal.
3. This seal prevents oil from escaping even under high pressure.

This way ORFS fittings do not rely on metal-to-metal sealing, which reduces the risk of leakage.

Where are Hydraulic ORFS Fittings used?

Hydraulic ORFS Fittings are used in systems where:

• There is very high hydraulic pressure.
• Machines operate under continuous vibration
• Oil leaks are completely unacceptable due to safety or cleanliness concerns

Applications:

• Construction and mining machinery
• Hydraulic power packs
• Oil and gas industry equipment
• Injection molding machines
• Heavy industrial equipment

In these applications, Hydraulic ORFS fittings are preferred for their consistent sealing performance and durability.

Benefits – Hydraulic ORFS Fittings

• Zero Leakage – Chance of oil leakage are very low
• Vibration Resistant doesn’t loosen
• Safe to open and reinstall repeatedly
• Extends the life of the hydraulic system
• Suitable for high pressure

Difference between ORFS Fittings & JIC Fittings

• In ORFS fittings the seal is made from an O ring while in JIC fittings have a metal to metal flare seal.
• ORFS fittings are considered much reliable then in High pressure and leak critical applications
• In short, Hydraulic ORFS Fittings are the best solution for hydraulic systems where high pressure, safety and leakage-free performance are essential.

Why Choose Us

The choice of fittings in a hydraulic system determines not only the product but also the reliability of the system. With this thought in mind, we offer hydraulic ORFS fittings and other hydraulic connection solutions.

• Genuine Solutions for High Pressure

Our fittings deliver stable and leak-free performance even under high pressure and vibration conditions.

• Strict quality control

Special attention is paid to the dimensional accuracy and sealing quality of each fitting.

• Application Based Guidance

We don’t just supply products, we also assist you in selecting the right fittings for your hydraulic application.

• Long Service Life

Our fittings help extend the life of hydraulic systems due to their superior sealing and material quality.

• Industrial Experience

Providing tailored solutions for various industries such as construction, mining, oil and gas, and heavy engineering.

FAQ

Q1. What does ORFS mean in hydraulic fittings?
ORFS stands for O Ring Face Seal, which refers to the sealing method used to prevent oil leakage in hydraulic systems.

Q2. Are hydraulic ORFS fittings suitable for high pressure systems?
Yes, ORFS hydraulic fittings are mainly designed for high pressure applications where leak free performance is required.

Q3. Can ORFS fittings be reused after removal?
Fittings can be reused if the O ring is undamaged or replaced.

In short, Hydraulic ORFS fittings are the best solution for hydraulic systems where high pressure, safety, and leakage free performance are essential.
